APC SURT96XLBP-CH(3U)Extended Battery Pack: Designed for use with SURT3000XLI-CH models

Purchase Support +0086 19710409880 Albert

APC SURT96XLBP-CH(3U) Extended Battery Pack: Designed for use with SURT3000XLI-CH models.

This APC Smart-UPS RT is designed for IT professionals or network administrators to maintain business uptime and continuity.

APC SURT96XLBP-CH(3U)Extended Battery Pack: Designed for use with SURT3000XLI-CH models

APC SMART UPS RT Series Products Order Checklist
Standard Model with
 Built-in Battery
Product Feature Description
SURT1000XLI-CH(2U)APC SMART UPS RT 1000VA/900W;230VAC;LCD Display; 48VDC
SURT2000XLI-CH(2U)APC SMART UPS RT 2000VA/1800W;230VAC;LCD Display; 48VDC
SURT3000XLI-CH(3U)APC SMART UPS RT 3000VA/2700W;230VAC;LCD Display; 96VADC
SURT5000XLI-CH(3U)APC SMART UPS RT 5000VA/5000W;230VAC;LCD Display; 192VDC
SURT6000XLI-CH(3U)APC SMART UPS RT 6000VA/6000W;230VAC;LCD Display; 192VDC
SURT8000XLI-CH(6U)RT 8000VA/8000W;Single-phase 230VAC;Three-phase 380VAC;
LCD Display; ±192VDC
SURT10000XLI-CH(6U)RT 10000VA/10000W;Single-phase 230VAC;Three-phase 380VAC;
LCD Display; ±192VDC
 Extended Runtime ModelProduct Feature Description
LCD Display; Extended 48VDC
LCD Display;Extended 48VDC
LCD Display;Extended 96VDC
LCD Display;Extended 192VDC
LCD Display;Extended 192VDC
SURT8000UXI-CH(6U) RT 8000UX/8000W;Single-phase 230VAC;Three-phase 380VAC;
LCD Display;Extended ±192VDC
SURT10000UXI-CH(6U)RT 10000UX/10000W;Single-phase 230VAC;Three-phase 380VAC;
LCD Display;Extended ±192VDC
SURT15KUXI-CH(6U) RT 15000UX/15000W;Single-phase 230VAC;Three-phase 380VAC;
LCD Display;Extended ±192VDC
SURT20KUXI-CH(6U) RT 20000UX/20000W;Single-phase 230VAC;Three-phase 380VAC;
LCD Display;Extended ±192VDC
Extended Battery PackProduct Feature Description
SURT48XLBP-CH(2U)Extended Battery Pack for  SURT1000/2000
SURT96XLBP-CH(3U)Extended Battery Pack for  SURT3000
SURT192XLBP-CH(3U)Extended Battery Pack for  SURT5K/6K/8K/10K
SURT192XLBP2-CH(6U)Extended Battery Pack for  SURT15K/20K
Replace Battery CartridgeProduct Feature Description
RBC31Replace By APCRBC48BP-CH
Replace Battery Cartridge for SURT1000XLICH/SURT2000XLICH
RBC44Replace By APCRBC140
Replace Battery Cartridge for  SURT3000XLICH/5K/6K/8K/10K
APCRBC140Replace Battery Cartridge for SURT3K/5K/6K/8K/10K/SURT96XLBP-CH/
APCRBC48BP-CHReplace Battery Cartridge for SURT1K/2K/SURT48XLBP-CH
APCRBC96BP-CHReplace Battery Cartridge for SURT3K/SURT96XLBP-CH
APCRBC192BP-CHReplace Battery Cartridge for SURT5K/6K/8K/10K/
Installation Accessories
Product Feature Description
SURTRK3-CHSuitable for SURT8K/10K/15K/20K/SURT192XLBP2-CH
Power Management
Product Feature Description
AP9641Third-generation network management card
with environmental monitoring capabilities,
supports SNMP, Modbus TCP, and BACnet
(built-in for 5-20kVA models).
AP9640Third-generation network management card,
supports SNMP, Modbus TCP, and BACnet.
AP9643Third-generation network management card
with environmental monitoring and Modbus
 support, compatible with SNMP, Modbus TCP,
 Modbus RTU, and BACnet.
AP9613Relay Input/Output Card
AP9810Relay Input/Output Accessory, provides additional
 dry contact interfaces for network
management cards such as AP9641/AP9643.
AP9834Provides Wi-Fi support for network management
 cards such as AP9641/AP9643.

This APC Smart-UPS battery pack, when connected with the SURT On-Line UPS, provides extended runtime for SRT mission-critical applications. Compatible with 3kVA SRT Smart-UPS extended runtime models, this 96V SURT extendable runtime battery pack offers embedded monitoring at the cell, module, and cabinet levels, providing data on battery runtime and health. It is a lead-acid battery with a 2-year warranty. The dimensions are 594mm (depth) x 432mm (height) x 85mm (width), and it weighs 40.6kg. Ideal for Smart-UPS On-Line mission-critical applications.



- Lead time: Usually in Stock

- Battery Type: Lead-Acid battery

- Provided Equipment: Documentation CD, User Manual, Warranty card

**Batteries & Runtime**

- Battery Slots Empty: 0

- Included Battery Modules: 0

- Battery Voltage: 96V

- RBC Quantity: 2

- Replacement battery: APCRBC152, SRT96RMBPUS


- Color: Black

- Height: 17.01 in (43.2 cm)

- Width: 3.35 in (8.5 cm)

- Depth: 23.39 in (59.4 cm)

- Net Weight: 89.51 lb(US) (40.6 kg)

- Mounting Mode: Rack-mounted with kit


- Ambient air temperature for operation: 32…104 °F (0…40 °C)

- Operating altitude: 0...10000 ft

- Relative Humidity: 0…95 % non-condensing

- Ambient Air Temperature for Storage: 5…113 °F (-15…45 °C)

- Storage altitude: 0…50000 ft (0.00…15240.00 m)

- Storage Relative Humidity: 0…95 % non-condensing

**Ordering and shipping details**

- GTIN: 731304317722

- Packing Units:

  - Unit Type of Package 1: PCE

  - Number of Units in Package 1: 1

  - Package 1 Height: 9.41 in (23.9 cm)

  - Package 1 Width: 32.72 in (83.1 cm)

  - Package 1 Length: 23.58 in (59.9 cm)

  - Package 1 Weight: 98.11 lb(US) (44.5 kg)

**Contractual warranty**

- Warranty: 2 years repair or replace
